PARD TA32-25 LRF thermal monocular

TA32/25 LRF Thermal Monocular


TA32 LRF series thermals are very versatile and can be used in a wide range of scenarios. The device is lightweight, handheld, pocket size and allows you to get personal with your surroundings for unique wildlife encounters. It's also easy to carry and fits comfortably in the palm of your hands.
12μm thermal imaging sensor can detect subtle differences in temperature and present perfect image detail in low thermal contrast conditions like rain and fog. The image sensor is designed with advanced technology to deliver organic and rich imaging despite adverse weather.
 The newly developed compact ranging module is precise and has fast detection speed. The LRF gives you the range information you need to accurately spot game at distances up to 1000m.
The PARD ultra-clear image algorithm has fast processing speed and strong real-time image adaptability. IREA can effectively improve image detail by correcting image distortion, reducing noise and enhancing contrast.
Featuring a quick switch function to choose between 3 scene modes (city/forest/rain). The image will be adjusted according to the selected scene mode offering exceptional adaptability in different environments.
The model is featuring multiple color palettes. You can choose any color palette to perfectly highlight a target. The user can select the appropriate color palette according to different environmental backgrounds during different weather changes : White Hot/Black Hot/Red Hot/Fusion1/Fusion2/Iron Red1/Iron Red2;
You can view magnified HD footage without distortion using the 8x digital zoom and 2x PIP zoom.


Sensor Type  uncooled VOx(vanadium oxide)
Resolution(px)   384*288
Pixel size(µm)  12*
NETD(mK)  ≤25mK（0.025℃）
Frame rate(Hz)     50
Human detection distance(m) 1100
Vehicle detection distance(m)   2200
Optic Objective lens  25
Optical magnification  2.2 x
Digital zoom(x)  2x-4x-6x-8x
PIP Zoom(x)    2x
Continuous digital zoom  2.6-41.6 x
Field of view (HxV)  7.9°
Eye relief(mm)   20
Diopter adjustment(D)   ±5D
Display type  AMOLED
Resolution(px)  1024*768
Scene mode   City,Rain,Forest
Image mode  WT-Hot,BK-Hot,RD-Hot,Fusion1,Fusion2,IronRed1,IronRed2
Photo resolution(px) 2592*1944
Photo format   JPG
Video resolution(px)  1024*768
Video format   MP4
Storage(GB)  TF card (128GB Max)
LRF detection range(m)  1000
Loop recording
Microphone  Yes
USB Tpye-C
HDMI Output
WiFi  Yes
Battery type  Lithium Ion 18650*1,  3,7V
Battery operating time(h)  ≤6h
External power supply(V) :  Type-C
Degree of environmental   protection  IP67
Operating temp(°C)  -20℃~50℃
Housing material Aluminium Alloy+Composite
Product dimension(L x W x H, mm)  182*57*71
Weight 298 gr
